OS-309Tension S type Load Cell

S-type compression sensor


Inquiry

Rated Capacity: 5/10/15/20/30/50/100/150t

Accuracy Class: D1

Rated Output: 2.0±0.002 mV/V(5~50t);

1.5±0.01 mV/V(100~150t)

Total error: ±0.05%F.S

Creep(30min): ±0.05%F.S

Input Resistance: 385±10Ω

Output Resistance: 350±2Ω

Operating Temperature: -10~+40℃

Safe Overload: 120%F.S

Destructive Load: 120%F.S

Excitation Recommend: 4~12VDC  Max:15VDC

Cable Length: 0.5~3m  4 wires with shield

Exc+(red) Exc-(black) Sig+(green) Sig-(white)

Construction: Alloy steel,IP67

Application for: crane scale, packing scale,tension testing etc.
