OS-308B Tension S type Load Cell
OS-308B Tension S type Load Cell
OS-308B Tension S type Load Cell
OS-308B Tension S type Load Cell
  • OS-308B Tension S type Load Cell
  • OS-308B Tension S type Load Cell
  • OS-308B Tension S type Load Cell

OS-308B Tension S type Load Cell

S-type compression sensor


Inquiry

Rated Capacity: 1/2/3/5/10/20t

Accuracy Class: C3

Rated Output: 2.0±0.1mV/V

Total error: ±0.02%F.S

Creep(30min): ±0.02%F.S

Input Resistance: 760±10Ω

Output Resistance: 701±10Ω

Operating Temperature: -10~+40℃

Safe Overload: 150%F.S

Destructive Load: 200%F.S

Excitation Recommend: 4~12VDC  Max:15VDC

Cable Length: 0.5~2m  4 wires with shield

Exc+(red) Exc-(black) Sig+(green) Sig-(white)

Construction: Alloy steel,IP67

Application for: Crane,packing scale,tension etc.
