Rated Capacity: 10/20/25/40/50/60/75klb
Accuracy Class: Class Ⅲ
Rated Output: 3.0±0.003 mV/V
Total error: ±0.02%F.S
Creep(30min): ±0.02%F.S
Input Resistance: 760±10Ω
Output Resistance: 702±2Ω
Operating Temperature: -10~+40℃
Safe Overload: 150%F.S
Destructive Load: 300%F.S
Excitation Recommend: 4~12VDC Max:15VDC
Cable Length: 8~16m 4 wires with shield
Exc+(red) Exc-(black) Sig+(green) Sig-(white)
Construction: Alloy steel or stainless steel,IP67
Application for: Weighing bridge,truck scale,
weighing module etc.
