OS-604SS High Strength Compression Load Cell

Single point sensor


Inquiry

Rated Capacity: 10/15/20/30/50/75/100/150/200kg

Accuracy Class: C3

Rated Output: 2.0±0.2 mV/V

Total error: ±0.02%F.S

Creep(30min): ±0.016%F.S

Input Resistance: 385±10Ω

Output Resistance: 350±3Ω

Operating Temperature: -10~+40℃

Safe Overload: 120%F.S

Destructive Load: 150%F.S

Excitation Recommend: 4~12VDC  Max:15VDC

Cable Length: 2m   4 wires with shield

Exc+(red) Exc-(black) Sig+(green) Sig-(white)

Construction: Alloy steel or stainless steel,IP67

Application for: stainless steel scales,waterproof scales.
