Rated Capacity: 0.05/0.1/0.2/0.5/1/2/5/10/20/30/50t
Accuracy Class: D1
Rated Output: 2.0±0.002 mV/V
Total error: ±0.1%F.S
Creep(30min): ±0.05%F.S
Input Resistance: 385±10Ω
Output Resistance: 350±2Ω
Operating Temperature: -10~+40℃
Safe Overload: 150%F.S
Destructive Load: 200%F.S
Excitation Recommend: 4~12VDC Max:15VDC
Cable Length: 3m 4 wires with shield
Exc+(red) Exc-(black) Sig+(green) Sig-(white)
Construction: Alloy Steel or Stainless steel,IP67
Application for: Hopper scale,testing machine for compression etc.
