OS-207 Compression Load Cell

Column load cell


Inquiry

OS-207 Compression load cell, using Weston bridge principle, alloy steel or stainless steel elastomer, with high precision strain gauge material which imported from European, using deep hole patch technology, imported glue. A high precision and high reliability weighing load cell is manufactured by fine process flow and high precision measuring equipment.

Process flowPatch (pre-cured, post-cured )→Bridge wire→ temperature compensation→Initial test→Sealing→Strain-hole laser weldingInitial test→ Standardized compensation→Retest→SealingCleaning glue Packing and storage


Rated Capacity: 20/25/30/40/50/60/70/100/150/200/300/400t

Accuracy Class: D1

Rated Output: 2.0±0.002mV/V

Total error: ±0.05%F.S

Creep(30min): ±0.02%F.S

Input Resistance: 385±10Ω

Output Resistance: 350±2Ω

Operating Temperature: -10~+40℃

Safe Overload: 150%F.S

Destructive Load: 200%F.S

Excitation Recommend: 4~12VDC  Max:15VDC

Cable Length: 8~16m  4 wires with shield

Exc+(red) Exc-(black) Sig+(green) Sig-(white)

Construction: Alloy Steel,IP68

Application for: testing equipment and special scale etc.
